RL-315 Heavy Duty Drum Lathe
R 220,000
The RL 315 Heavy Duty Drum Lathe went into production on a limited basis in 2000. Over the course of 20 years it has been developed, iterated and enhanced to become an icon in the African brake and clutch industry.
Developed to be versatile in terms of its ease of deployment, operation and maintenance, this workhorse can be deployed into the most challenging environments.
The RL-315 can accommodate all drum brakes from all truck and trailer manufacturers.
Specification
Chuck Diameter - 315 mm
Max Turning Diameter - 800 mm
Main Motor Speed - 45 rpm
Feed Motor Speed - 26 rpm
Height - 1,800 mm
Width - 400 mm
Length - 1,200 mm
Weight - 700 kg
RL-150 Surface Grinder
R 125,000
This surface grinder is configured with a swing arm, making faster and easier to setup and work. A high day light clearance makes it a versatile grinder machine across many applications including;
- Grinding of steel and slug
- Grinding of carbon
- Sharpening of fastening tools
- Flyingwheel grinding
Specifications
Grinding wheel size - 150 x 50 x 31.75 mm
Magnetic table - 150 x 300 mm
Maximum working height - 330 mm
Motor speed - 2,800 rpm
Motor rating - 0.55 kW
Working space with cabinet - 760 x 500 mm
Working space without cabinet - 430 x 430 mm
Weight with cabinet - 85 kg
RL-700 Clutch Setting Table
R 90,000
The clutch setting table is made to rebuild clutch plates for trucks and cars. This versatile machine comes fully equipped to cater for all types of clutches and include 16 different size spacers.
Specification
Table Diameter - 700mm
Outside Diameter - 1,100 mm
Control values - 2
Regulator - 1
Options - 3, 4 or 6 Arm
Included:
- Setting pads - 16 sets of 3
- Jacking bolts
- Clamping arms
- Stepped Shaft with keep plate
- Clamping pedestals
RL-500 Clutch Stripping Table
R 50,000
This machine is for stripping clutches therefore resolving the need to tie up your setting table for this task.
Specification
Table Diameter - 500 mm
Outside Diameter - 700 mm
Cylinder - 160 mm diameter by 200 mm stroke
Hand control values - 1
Regulator filter lubricator - 1
Spider three point - 1
Weight - 85 kgs
RL-150 Cap and Rod Grinder
R 50,000
This machine is made for grinding conrods that have become oversized. It can grind the butts (faces) of both sides of the conrod therefore reducing the diameter of the conrod so it can be resized.
Specification
Grinder wheel size - 150 x 50 x 31.75 mm
Adjustable plate size - 180 x 60 mm
Grinding wheel speed - 1,450 rpm
Table feed - 1 mm/rev
Motor rating - 0.55 kW
Weight - 55 kg
Height - 430 mm
Working space - 370 x 450 mm
RL-100 Shim Grinder
R 50,000
This machine is primarily used in the grinding of shims for valve setting on cylinder heads, however it can grind a wide variety of small parts.
When the valve is reground the same shim can be reused by grinding it, negating a new shim purchase.
Specification
Grinding wheel size - 100 x 50 x 20mm
Magnetic bed size - 200 x 100mm
Max working height - 45mm
Motor speed - 2,800 rpm
Motor - 0.37 kW
Working space - 600 x 360 mm
Height - 450mm
Weight - 50 kg
